| Model name |
EQ-03SW |
|---|
| Appearance Specification (mm) |
Length |
1000 |
| Width |
740 |
| Height |
1850 |
| Weight(Kg) |
148 |
| Drying capacity * |
Dried amount based on red pepper(Kg) |
55 ~ 100 |
| Number of trays (ea) |
12 |
| Size of tray (㎟) |
885 X 605 X 50 |
| Spacing of trays (㎜) |
100 |
| Electricity Specification |
220V * 60/50Hz * Single Phase |
| Electric heater |
Type |
Pin-tube type |
| Heat generation (㎾) |
3.0 |
| Blower |
Type |
Turbo Type |
| Motor Power (㎾) |
0.35 |
| Temperature control |
Type |
Digital Thermostat Type |
| Measurement temperature |
Dry-bulb temperature |
| Control range |
Room temperature to 70℃. |
* Drying capacity is measured on a standard shelf
