Electric dryer



PRODUCT

Dongho Agrimecha offers
the best products.

Electric dryer

EQ-05SW

Characteristics
– Small and Medium-Sized Multipurpose Food Dryer
– Even and fast drying with hot air from the left and right sides
– Excellent durable pin type electric heater
– Powerful Turbo-type blower application blower
– Simple design and caster-type wheels increase convenience of installation and movement

본문

Standard Specifications < Standard Specifications can be adjusted to meet customer requirements>

Model name EQ-05SW
Appearance Specification (mm) Length 1000
Width 1440
Height 1850
Weight(Kg) 267
Drying capacity * Dried amount based on red pepper(Kg) 110 ~ 200
Number of trays (ea) 24
Size of tray (㎟) 885 X 605 X 50
Spacing of trays (㎜) 100
Electricity Specification 220V * 60/50Hz * Single Phase
Electric heater Type Pin-tube type
Heat generation (㎾) 6.0
Blower Type Turbo type
Motor Power(㎾) 0.7
Temperature control Type Digital Thermostat Type
Measurement temperature Dry-bulb temperature
Control range Room temperature to 70℃.

* Drying capacity is measured on a standard shelf
